Flatcar Container Linux has a strong focus on backwards compatibility. Being a continuation of the CoreOS Container Linux project which started more than 10 years ago, the main design stayed as is. Flatcar ships a fixed set of software and users should rely on containers for the rest. This has proven successful but there are some scenarios where one has to extend Flatcar in ways the original design wasn’t intended for. Luckily, Flatcar still evolves, though, to make it even more suited for reliable infrastructure automation.

Two examples for cases where the fixed set of software is limiting are the following. First, to run in cloud environments Flatcar needs to ship the cloud vendor tools but we can’t pack all of them into the base image. Second, users sometimes need custom versions of Docker/containerd and other OS-level software that can’t be a container itself. When such additional software is brought in as a bunch of files placed on the root filesystem, we faced problems with updating them and with the lack of integration with the base OS. We now have a solution to extend Flatcar that provides a robust update mechanism and integrates well with the base OS.

With systemd-sysext we can overlay extensions on top of the read-only /usr partition. This allows us to address long-standing feature requests and find new solutions outside of previous compromises. The team has mentioned systemd-sysext in many conference talks and it is also a constant topic in the Flatcar Dev Syncs and Office Hours. Being an early adopter, we contributed missing features and have ideas for outstanding limitations. In this post we summarize the added systemd-sysext features in Flatcar, and the changes we expect to make in the future.

User-provided Software

While most software is deployed as containers, this is not possible for certain host-level software such as the container runtime itself. ​So far, one had to place binaries under /opt/bin and keep track of them for updating, or use Torcx to switch the inbuilt Docker/containerd version to a custom Torcx bundle. With systemd-sysext there is now a more generic solution for user-provided software with deep OS-level integration. Therefore, we recently removed Torcx and recommend using systemd-sysext for deploying custom Docker/containerd versions. Flatcar’s inbuilt Docker/containerd versions are in fact systemd-sysext images ​already, so that they will fully disappear when disabled.

To help users extend Flatcar with systemd-sysext, we provide build recipes for common software projects and publish prebuilt extension images in the sysext-bakery repository . Since the lifecycle of the extensions is decoupled from Flatcar OS updates, user-provided extensions should consist of static binaries instead of linking against OS libraries. ​Currently​, the published extensions are based on official release binaries of the various projects. Besides Docker and containerd, the repository offers extensions providing binaries for Kubernetes, CRI-O, K3s, Wasmtime, and wasmCloud. Extensions can be updated with systemd-sysupdate , and the sysext-bakery repository provides the configuration to set it up.

The customization of the OS at provisioning time combined with the ability to update the additions is also interesting for the Kubernetes Cluster API project. ​Until now, ​the approach has been to prepare custom images with​ ​ Kubernetes image-builder and upload these images to the cloud providers. With ​systemd-sysext, one can use the Flatcar images available in the cloud marketplaces and deploy the Kubernetes binaries at provisioning time. The additional benefit of updating Kubernetes binaries with systemd-sysupdate would then enable in-place Kubernetes updates. The latest release of the Kubernetes ClusterAPI for OpenStack (CAPO) provider already supports a flatcar-sysext variant

Cloud Vendor Tools and Flatcar Extensions

Another area where systemd-sysext serves as an elegant solution is providing cloud vendor tools. To make Flatcar work on the various clouds we often need the OEM images to contain integration software provided by the cloud vendor. Adding these to the base image would ​waste disk space for all users and the old approach was to put these binaries on the Flatcar OEM partition. The problem was that there was no update/rollback mechanism for the scattered files and the custom location was also not ideal for a ​good integration due to diverging from an expected standard path.

Now the cloud vendor tools in Flatcar are layered on top of ​the ​/usr partition through systemd-sysext images. They are covered by the Flatcar A/B update/rollback mechanism and provided as additional update payloads by our update server . The extensions are coupled to the OS version to ensure that they are compatible ​and, therefore, ​can make use of dynamic linking to save disk space.

Having established a mechanism for A/B-updated extensions that are bound to the OS version, Flatcar has become more modular. In the past we had to find a compromise between user demands and the image size. The first optional Flatcar extension we introduced provides the kernel drivers and CLI utilities for the ZFS out-of-tree filesystem. We plan to make more CLI tools available such as htop or tmux and cover more use cases with a Podman and Incus extension. The NVIDIA kernel driver is also a candidate for a Flatcar extension. At the same time we can look into reducing the base image size by splitting out some less common parts such as sssd and Kerberos into extensions, likely pre-enabled for backwards compatibility.

Looking Forward

Currently the extensions get loaded quite late in the bootup, where kernel module settings, udev rules, or systemd target dependencies have already been processed. This means that the extension needs to work around this by explicitly applying the required settings. In general, this behavior is always needed if extensions get loaded after the system is up, but for ​many software projects the additional modifications required for live loading might not be worth adding because one can also require a reboot. To make unmodified software work, we want to mount the extension overlay ​during​ the initrd stage for the final system to boot up fully configured. Another limitation is that during an extension reload the overlay mount shortly disappears. We want to fix this by using the new Linux mount beneath API . The integrity of extension images can be protected with dm-verity but we need more granular policies to enforce this for OS extensions by default. For systemd-sysupdate we want it to run on first boot from the initrd to download missing extensions. We also think that downgrade support in the manifest format would be beneficial to retract a broken update.

Managing Configuration and Building a Bridge to Traditional Distros

With systemd-confext users can load extension images for /etc, thus managing their configuration in a reliable way. Up to now, the overlay mount was strictly read-only which doesn’t yet work well for all use cases. Also, Flatcar already has an overlay mount for /etc which provides the default configuration files of the active /usr partition, which keeps /etc updated without accumulating old state. A file is only copied to the original /etc directory on the root filesystem when it gets modified by the user. To make use of systemd-confext we contributed a mutable overlay mode to systemd-confext and systemd-sysext. This way we can soon switch the custom /etc overlay to provide the default configuration through a systemd-confext image. The mutable mode where the original directory becomes the upperdir of the overlay mount is also what is needed to load systemd-sysext images on traditional Linux distributions where /usr must be writable for the package manager.


The use of systemd-sysext in Flatcar lets us innovate in the design of the image-based OS. ​If you are​ interested in these new developments, then good news, many features are already available in the Flatcar Stable channel, and others are staged in the Alpha and Beta channels. The ​foundation is prepared, and we want to build on it to split Flatcar into composable OS layers. There are still some rough ​edges, but users are encouraged to try the new systemd-sysext features and contribute more extensions to the sysext-bakery repository . Help is also welcome with the planned Flatcar extensions and the upstream improvements for systemd-sysext. We hope that the mutable overlay mode will make systemd-sysext and systemd-confext more accessible for traditional distributions.

In summary, making Flatcar more modular addresses many pain points while keeping the valued simplicity and reliability. The optional OS layers differ fundamentally from a package manager system and are not meant to be used like one. We hope that systemd-sysext grows to address more corner cases and gains adoption in other Linux distributions. The next iteration of the Image-based Linux Summit and the “All Systems Go!" conference are good community spaces to discuss this. In the meantime, feel free to join the Flatcar Office Hours and Matrix chat to bring up your use case.
